Software Calculation Double Girder Crane

Description

Software Features V.2:
Added GA / General Arrangement output
Checking the bridge connection to the longitudinal carriage
Accurate structural weight optimization
Adding bridge connections to the longitudinal carriage/TOP, SIDE, CUTTING
Software Features V.I:
Calculations for determining bridge dimensions
Structural stress and fatigue calculations
Structural calculations based on working group
Bridge camber calculations and vertical displacement values
Selecting the number and diameter of longitudinal wheels
Determining the appropriate longitudinal rail based on the crane’s working conditions
Calculation and selection of lifting motor, transverse longitudinal
Calculating the dimensions of the longitudinal carriage
Longitudinal carriage stress calculations
Choosing a frame box and tube for a long stroller
Calculating the exact weight of the structure
Simultaneous investigation and analysis of I and A longitudinal wheel carriages
Choosing the size and cross rail wheel
And ….
