Description
This software allows you to analyze and confirm the design of your desired crane with its working conditions in less than a few minutes, without the need for a computer engineer, and prepare a PDF output to present to the employer.
This software allows you to analyze and confirm the design of your desired crane with its working conditions in less than a few minutes, without the need for a computer engineer, and prepare a PDF output to present to the employer.
1- Checking the dimensions of the Boom and analyzing its stress and fatigue
2 – Structural design based on crane working group
3 – Calculation of Boom displacement in dead and live load conditions as well as calculation of boom camber
4 – The importance of calculating the thickness of the bottom flange of the boom for a jib crane
5 – Calculating and selecting column diameter and thickness
6 – Calculating the thickness of the base plate JIB Crane
7 – Calculating Base Plate Dimensions
8 – Calculation of concrete foundation under base plate
9 – Calculating the load and torque acting on sensitive points of the crane
10 – Calculation of welding stress in base plate and column
11 – Choosing and comparing Boom Box and Boom Beam at the same time
12 – Calculating the exact weight of the crane to present to the employer or participate in tenders and calculate the construction cost
